SkyWatcher EQ3-2 SynScan PRO GOTO Upgrade Kit

Name: SkyWatcher EQ3-2 SynScan PRO GOTO Upgrade Kit
Brand: Skywatcher
SKU: 6970456093427
Price: 385.0 GBP
Availability: InStock
Rating: 5 (1 reviews)

Ask a Question

£385.00
Inc VAT & Warranty

Availability - In stock

REF: 20107

Quantity:

Product Description

A full upgrade kit with everything required for easily upgrading the standard (non-PRO) EQ3-2 mountings for computerised GOTO capabilities. Kits comprise SynScanTM Flash Upgradeable GOTO handset, 2 x Stepper Motors for DEC and R.A. Drives, Replacement Control Panel / Motor Board, Hand Control Cable, Cable Clamp and Hand Control Holder (12V D.C. Power Supply required - not supplied).

Further details

Tour the night sky at the touch of a button

Hardware Features:
SynScan Updateable Hand Control
New features include ongoing firmware updateability via the internet, Pointing Accuracy Enhancement (PAE), and capability to store star alignment data.
High precision stepper motors
Motor Controller: Microstep driving with auto-power saving feature
Resolution: 0.288 arc second
Slew Rate: 0.5x, 1x, 8x, 16x, 32x, 64x, 400x, 500x, 600x, 800x
Tracking Rate: Sidereal, Lunar, Solar
Tracking Mode: R.A. tracking
ST-4 type Autoguider Interface: Support 0.25x, 0.5x, 0.75x 1x guiding rate
Power requirement: 11 to 15 V DC 2 Amp (Tip positive) (Power supply not included)

Software Features:
Alignment Method: One-Star Alignment, Two-Star Alignment, Three-Star Alignment
Pointing Accuracy: Up to 1 arc min
Object Catalogues: Messier, IC, NGC, Caldwell
13740 Object Database: Including Planets, Named Stars, Double Stars, Variable Stars & User-Defined Objects
Backlash compensation
Periodic Error Correction
Premium PC Interface: ASCOM compatible, Nexstar-5i compatible protocol and command set
User-tunable LCD contrast, LED backlight and buzzer volume

Please note: this product requires fitting with precision and care aligning gears and attaching motor housings, only basic instructions are included from the manufacturer.

Delivery charge £5.95

Delivery Information

We are closed from December 20th until January 3rd, most orders placed when we are closed will not ship until the New Year.

Our delivery charge is £5.95* fully insured. Orders received before 2PM normally ship that business day. We also ship direct from our suppliers all fully tracked and insured.

All goods are shipped with UPS, DPD, DHL, APC, DX Express, ParcelForce and Royal Mail, we do not use budget couriers, we only ship to UK mainland addresses and do not ship to forwarding agents or PO boxes.

Our Order Lookup system (see link at the top and bottom of each page) updates the order status in real time - simply enter your order number and postcode..

*Some exceptions apply with AB, FK, HS, IV, KA, KW, PA, PH, ZE postcodes. We will quote delivery charges if applicable prior to shipping (this does not normally affect lower value items shipped by Royal Mail).

Reviews

Customer Reviews

10/10 EQ3 pro upgrade kit Great piece of kit to make my mount fully goto. Easy to fit and use. Harrison Telescopes could not have sent it any quicker. Thank you (22/04/2022) jax - Sussex
